Chain Link 2 1/2" [2 3/8" OD] Corner Brace Band (90 Degree Brace Band) HDG
Details
Chain Link 2 1/2" [2 3/8" OD] Corner Brace Band (90 Degree Brace Band) HDG
The 2 1/2" [2 3/8" OD] corner brace band is a 90-degree rail end band for Chain-Link Fence Frame Work at corner posts where fence lines meet at a right angle. The 90-degree profile lets end rails attach cleanly to the post without requiring additional adapters. Two are required per corner post, one at the top and one at the bottom. Made from hot-dip galvanized steel to hold up in outdoor conditions. Bolts are sold separately. Find matching galvanized carriage bolts and nuts to complete your order.
Features:
- 90-degree profile for corner posts where fence lines meet at a right angle
- Allows end rail connections at the corner post
- Two bands required per corner post, one at the top and one at the bottom
- For Chain-Link Fence Frame Work
- Bolts sold separately
Specifications:
- Post Size: 2 1/2" [2 3/8" OD]
- Material: Galvanized steel
- Finish: Hot-dip galvanized finish
| SKU | BB212-C |
|---|---|
| Gauge | 12 Gauge |
| Height | 7/8" |
| Band Type | Corner (90 Degree) |
| Material Type | Pressed Steel |
| Uses Carriage Bolt Size | 5/16" x 1 3/4" |
Post Size
Need to know the difference between Pipe and Gate Frame Sizes? Check out our guide!
Learn More
|
2 1/2" [2 3/8" OD] |
| Finish | Hot-Dipped Galvanized |
